Description:
●Rugged NTEP approved industrial construction for heavy duty weighing;
●Safety chequered plate to protect from slipping on the scales;
●Powder coated finish;
●4 load cells are installed and calibrated before shipment;
●Adjustable swivel leveling legs;
●Overload protection;
Options:
Ramp; Moveable Pole; customs size and design.
ITEM | Dimension | Max. Cap. | Division | Platform height(mm) | N.W |
(m×m) | (Tonne) | (kg) | (kg) | ||
WSF0011-1/2/3-1010 | 1×1m | 1/2/3t | 0.2/0.5/1 | 110 | 80 |
WSF001-5-1010 | 1×1m | 5t | 1 | 110 | 90 |
WSF001-1/2/3-1212 | 1.2×1.2m | 1/2/3t | 0.2/0.5/1 | 110 | 105 |
WSF001-5-1212 | 1.2×1.2m | 5t | 1 | 110 | 115 |
WSF001-1/2/3-1215 | 1.2×1.5m | 1/2/3t | 0.2/0.5/1 | 110 | 125 |
WSF001-5-1215 | 1.2×1.5m | 5t | 1 | 110 | 140 |
WSF001-1/2/3-1515 | 1.5×1.5m | 1/2/3t | 0.2/0.5/1 | 110 | 150 |
WSF001-5-1515 | 1.5×1.5m | 5t | 1 | 110 | 170 |
Products Detail:
The Ramp(Optional):
One corner of the production workshop:
Extensive inventories,preclude shortages:
Description:
●Rugged NTEP approved industrial construction for heavy duty weighing;
●Safety chequered plate to protect from slipping on the scales;
●Powder coated finish;
●4 load cells are installed and calibrated before shipment;
●Adjustable swivel leveling legs;
●Overload protection;
Options:
Ramp; Moveable Pole; customs size and design.
ITEM | Dimension | Max. Cap. | Division | Platform height(mm) | N.W |
(m×m) | (Tonne) | (kg) | (kg) | ||
WSF0011-1/2/3-1010 | 1×1m | 1/2/3t | 0.2/0.5/1 | 110 | 80 |
WSF001-5-1010 | 1×1m | 5t | 1 | 110 | 90 |
WSF001-1/2/3-1212 | 1.2×1.2m | 1/2/3t | 0.2/0.5/1 | 110 | 105 |
WSF001-5-1212 | 1.2×1.2m | 5t | 1 | 110 | 115 |
WSF001-1/2/3-1215 | 1.2×1.5m | 1/2/3t | 0.2/0.5/1 | 110 | 125 |
WSF001-5-1215 | 1.2×1.5m | 5t | 1 | 110 | 140 |
WSF001-1/2/3-1515 | 1.5×1.5m | 1/2/3t | 0.2/0.5/1 | 110 | 150 |
WSF001-5-1515 | 1.5×1.5m | 5t | 1 | 110 | 170 |
Products Detail:
The Ramp(Optional):
One corner of the production workshop:
Extensive inventories,preclude shortages:
